PeakTech P 1265 30 MHz/2CH, 250 MS/s, Digital Storage Oscilloscope

SKU: P 1265 Category: Tag:

399.00Excluding Tax

Request a Quote

Description

Description

The PeakTech 1265 is an affordable 30 MHz 2-channel digital storage oscilloscope with a high-resolution TFT color display and extensive additional functions. It has a sampling rate of up to 250 MS / s and convinces with its high quality and easy handling with the best price / performance ratio. To quickly display each incoming waveform, simply press the Autoset key and the oscilloscope itself searches for the best possible display. With Autoscale, however, the scaling of the time base can be adjusted in a user-friendly manner. This oscilloscope has a VGA output for displaying the oscilloscope display on an external monitor or projector.

Specification

Sampling 1 CH: 250 MS/s
Sampling 2 CH: 125 MS/s
USB:
Bandwidth: 30 MHz
Channels: 2 CH
Display Type: Color-TFT
Hor. scale max.: 100 s/div
Hor. scale min.: 5 ns/div
LAN:
Mains voltage: 110/240 V AC; 50/60 Hz
Memory depth: 10.000 Points
Resolution: 800 x 600 Pixel
Rise Time: < 14 ns
Screen size (TFT): 20 cm (8″)
VGA:
Vert. resolution: 8 Bit
Vert. scale max.: 10 V/div
Vert. scale min.: 2 mV/div
